Table 10: Display menu: Three-phase network measuring with 4-wire connection.
Display menu: Three-phase network measuring with 4-wire connection.
2206
L1
2207
2208
V
L2
L3
.
.
.
Phase-Neutral Voltage (V / kV)
(3)
3800
L1-2
3801
3803
V
L2-3
L3-1
.
.
.
Phase-Phase Voltage (V / kV)
(3)
5011
L1
5012
5013
A
L2
L3
.
.
.
Current (A / kA)
(4)
5000
Hz
.
Frequency (Hz)
5701
L1
5703
5704
W
L2
L3
Active power per phase (W)
(3)
For values of V ≥ 9000, the device automatically switches the units to kV.
(4)
For values of A ≥ 9000, the device automatically switches the units to kA.
