31
Instruction Manual
CVM-C4
Table 11 (Cont.). Display menu: Three-phase network measuring with 3-wire connection.
Display menu: Three-phase network measuring with 3-wire connection.
tHd
ib
0305
THD
%
.
THD Current L2
tHd
iC
0311
THD
%
.
THD Current L3
di
12
Status of digital inputs
1, status of digital input 1: flashes when the input has been activated.
2, status of digital input 2: flashes when the input has been activated.
do
12
Status of relay outputs
1, status of relay output 1: flashes when the relay has been activated.
2, status of relay output 2: flashes when the relay has been activated.
If the input voltage or current value is higher than a % of the nominal value, the device can make the
digits on the display start flashing, in the form of a light alarm. See “6.5.6.- LIGHT ALARM”
Note: If a display screen shows FFFF, check the programming of the transformation ratios.
