Cirrus SR22T - Page 238

7-32 P/N 13772-005
Section 7 Cirrus Design
Systems Description SR22T
Figure 7-7
Engine Controls and Indicating
Density Alt 8000 Ft
Oat 31°F -1°C (ISA +0°C)
8
Engine Instruments
Engine Controls
9
10
1345 6
LEGEND
1. Percent Power
2. CHT
3. Tachometer
4. EGT
5. Manifold Pressure
6. Oil Temperature
and Pressure
7. Turbine Inlet Temperature
8. Power Lever
9. Friction Control
10. Mixture Control
2
SR22_FM07_3255A
7
Original Issue
