Figure 7-9
Fuel System Controls and Indicating
3
Density Alt 8000 Ft
Oat 31°F -1°C (ISA +0°C)
2
4
1
Fuel System Indication
LEGEND
1. Fuel Flow Gage
2. Fuel Calculations:
·Fuel At Destination (Totalizer)
·Fuel Used (Totalizer)
·Fuel Remaining (Totalizer)
·Time Remaining (Totalizer)
·Fuel Range (Totalizer)
·Nautical Miles Per Gallon (Totalizer)
3. Fuel Quantity Gage (Float Sensor)
4. Fuel Pump Switch
5. Fuel Selector Valve
