Cirrus SR22T User Manual

7-48 P/N 13772-005
Section 7 Cirrus Design
Systems Description SR22T
Figure 7-10
Electrical System Schematic
STALL
VANE HEAT
CABIN AIR
CONTROL
30A
BAT 2
SWITCH
BAT 2
AVIONICS
SWITCH
20A
8A
8A
20A
VOLT REG
BAT 1
SWITCH
EXTERNAL
POWER
MAIN DIST BUS 2
50A
50A
80A
BAT 1
RELAY
30A
30A
30A
STARTER
SWITCH
AVIONICS
NON-ESSENTIAL
RELAY
30A
30A
STARTER
125A
EXTERNAL
POWER RELAY
STARTER
RELAY
LANDING
LIGHT
LANDING LIGHT
SWITCH
7.5A
BAT 1
ALT 1
RELAY
MAIN DIST BUS 1
30A
ALT 1
FB
100A
VOLT REG
MASTER CONTROL UNIT
ALT 1
SWITCH
DME / ADF
AVIONICS BUS
AUDIO
PANEL
WEATHER
/ DATA LINK
TRAFFIC
XPONDER
STDBY
ATTD #2
MFD #2
MAIN BUS 1
CABIN LIGHTS
/ OXYGEN
FUEL QTY
KEYPADS
/ AP CTRL
AP SERVOS
AVIONICS
ICE
PROTECTION
ESSENTIAL BUS 2
ENGINE
INSTR
STALL
WARNING
PITCH
TRIM
ROLL
TRIM
GPS NAV
GIA 1
COM 1
ESSENTIAL BUS 1
ADC 1
AHRS 1
PFD #1
STDBY
ATTD #1
ESSENTIAL
POWER
BAT 2
A/C BUS 1
A/C COND
ALT 1
MFD #1
MAIN BUS 3
12V DC
OUTLET
YAW
SERVO
GPS NAV
GIA 2
COM 2
MAIN BUS 2
AHRS 2/
(ADC 2)
PFD #2
FUEL
PUMP
AVIONICS
FAN 2
ALT 2
A/C BUS 2
CABIN
FAN
A/C COMPR
NAV
LIGHTS
STROBE
LIGHTS
NON-ESSENTIAL BUS PITOT
HEAT
FLAPS
STARTER
AVIONICS
FAN 1
RECOG
LIGHTS
ALT 2
SWITCH
CIRCUIT BREAKER PANEL
SR22_FM07_2806B
ESSENTIAL DIST BUS
30A
30A
ALT 2
FB
80A
50A
EVS
CAMERA
Original Issue

Cirrus SR22T Specifications

General

Manufacturer	Cirrus Aircraft
Engine	Continental TSIO-550-K
Horsepower	315 hp
Max Takeoff Weight	3, 600 lbs
Service Ceiling	25, 000 ft
Cabin Width	49 in
Cabin Height	50 in
Seating Capacity	4
Avionics	Cirrus Perspective+ by Garmin
Category	Single-engine piston aircraft
Propeller	Hartzell 3-blade composite
Wingspan	38 ft 4 in
Length	26 ft
Height	8 ft 11 in
Maximum Cruise Speed	213 KTAS
Fuel Capacity	92 gallons
Stall Speed	64 knots
Safety Features	Cirrus Airframe Parachute System (CAPS)
Cruise Speed	183 knots
