Cirrus SR22T User Manual

4 of 8 P/N 13772-131
Section 9 Cirrus Design
Supplements SR22 / SR22T
Portable Use of ELT
The ELT transmitter can be removed from the airplane and used as a
personal locating device if it is necessary to leave the airplane after an
accident. Access the unit as described below and set the ELT
transmitter control switch to the 'ON'-position.
1. Remove avionics bay access panel along the aft portion of the RH
fuselage or the lower aft center access panel of baggage
compartment.
2. Disconnect fixed antenna lead from front of unit.
3. Disconnect lead from remote switch and indicator unit.
4. Disconnect antenna from mounting tray.
5. Loosen attach straps and remove transmitter unit.
6. Attach antenna to antenna jack on front of unit.
7. Set main control switch to ON.
8. Hold antenna upright as much as possible.
Section 4 - Normal Procedures
No Change.
Section 5 - Performance
No Change.
Section 6 - Weight & Balance
Installation of the subject propeller adds the following optional (Sym =
O) equipment at the weight and arm shown in the following table.
ATA /
Item
Description Sym Qty Part Number
Unit
Wt
Arm
25-01 Artex ME406 ELT and Batteries O 1 17190-100 3.4 229.5
Revision 02: 01-06-10

Cirrus SR22T Specifications

General

Manufacturer	Cirrus Aircraft
Engine	Continental TSIO-550-K
Horsepower	315 hp
Max Takeoff Weight	3, 600 lbs
Service Ceiling	25, 000 ft
Cabin Width	49 in
Cabin Height	50 in
Seating Capacity	4
Avionics	Cirrus Perspective+ by Garmin
Category	Single-engine piston aircraft
Propeller	Hartzell 3-blade composite
Wingspan	38 ft 4 in
Length	26 ft
Height	8 ft 11 in
Maximum Cruise Speed	213 KTAS
Fuel Capacity	92 gallons
Stall Speed	64 knots
Safety Features	Cirrus Airframe Parachute System (CAPS)
Cruise Speed	183 knots
