Cirrus Design Section 9
SR22T Supplements
Left/Right Fluid Quantity Caution
PFD Alerts Window: “Right/Left tank fluid quantity is unreliable (TKS)”
L / R fluid quantities on Anti Ice - TKS block of ENGINE page is
“greyed out” and/or fluid quantity is marked with a “Red X”. The deicing
fluid sensing system has detected conflicting system information
regarding the fluid quantity in the tanks.
1. Revert to manual control of the fluid source to control the fluid level
quantity.
If ANTI ICE FLO or ANTI ICE PSI annunciates:
a. Fluid Quantity ......................... SWITCH TO OPPOSITE TANK
b. WIND SHLD Push-Button ............................................ PRESS
(1) Repeat operation of windshield pump to verify metering
pumps are primed properly as evidenced by deicing fluid
exiting windshield nozzles.
Dynamic Stall Speed Band Unavailable Advisory
PFD Alerts Window: “Dynamic stall speed band is unavailable.”
Angle of Attack signal has failed. This signal is used to calculate and
display a dynamic stall speed awareness band (red band) on airspeed
tape. With a failed AOA signal, the low speed red band extends to a
fixed value of 61 knots.
ANTI ICE LVL
AOA FAIL
Original Issue: 02-01-13

Cirrus SR22T Specifications

General

Manufacturer	Cirrus Aircraft
Engine	Continental TSIO-550-K
Horsepower	315 hp
Max Takeoff Weight	3, 600 lbs
Service Ceiling	25, 000 ft
Cabin Width	49 in
Cabin Height	50 in
Seating Capacity	4
Avionics	Cirrus Perspective+ by Garmin
Category	Single-engine piston aircraft
Propeller	Hartzell 3-blade composite
Wingspan	38 ft 4 in
Length	26 ft
Height	8 ft 11 in
Maximum Cruise Speed	213 KTAS
Fuel Capacity	92 gallons
Stall Speed	64 knots
Safety Features	Cirrus Airframe Parachute System (CAPS)
Cruise Speed	183 knots
