Cirrus SR22T - Page 54

2-28 P/N 13772-005
Section 2 Cirrus Design
Limitations SR22T
Figure 2-7
(Sheet 5 of 6)
Instrument Panel, center:
DISPLAY
BACKUP
GRAB HERE
Bolster Panel, both sides:
ELT LOCATED BEHIND BULKHEAD
REMOVE CARPET AND ACCESS PANEL
Baggage Compartment, aft edge:
F
I
R
E
E
X
T
I
N
G
U
I
S
H E
R
F
O
R
W
A
R
D
L
E F
T
O
F
P
I
L
O
T
S
E A T
FASTEN SEATBELTS • NO SMOKING
Instrument Panel:
EMERGENCY EXIT
REMOVE EGRESS HAMMER FROM WITHIN
CENTER ARMREST LID. STRIKE CORNER OF
WINDOW. KICK OR PUSH OUT AFTER FRACTURING
Cabin Window, above door latch:
DISTRIBUTED FLOOR LIMIT 130 LBS
BAGGAGE STRAP CAPACITY IS 35 LBS EACH MAXIMUM
SEE AIRPLANE FLIGHT MANUAL FOR BAGGAGE TIE-DOWN
AND WEIGHT AND BALANCE INFORMATION
Baggage Compartment Door, inside:
SR22_FM02_2684
Original Issue
