Cisco 11503 - CSS Content Services Switch Configuration Guide

5-7
Cisco Content Services Switch SSL Configuration Guide
OL-5655-01
Chapter 5 Configuring Back-End SSL
Configuring Back-End SSL Servers in an SSL Proxy List
Configuring the Server IP Address
The server IP address is the IP address for the back-end SSL server. To configure
the server IP address for the back-end server, use the backend-server number
server-ip command.
For example, to configure the server IP address 192.168.2.3, enter:
(config-ssl-proxy-list[ssl_list1])# backend-server 1 server-ip
192.168.2.3
To remove the server IP address from the back-end server, enter:
(config-ssl-proxy-list[ssl_list1])# no backend-server 1 server-ip
Note If you do not configure the server IP address when you issue the active command,
the following error message appears and the CSS does not activate the list.
SSL-server/Backend-server must have valid IP address
Configuring the Server Port
By default the server port for the back-end SSL server is port 443. To configure a
different server port for the SSL back-end server, use the backend-server number
server-port command. Enter a port number from 1 to 65535.
Note If you configure the backend-server number ip address and server-ip commands
with the same address, configure the backend-server number port and
server-port commands with different port numbers.
For example, to configure the server port number 155, enter:
(config-ssl-proxy-list[ssl_list1])# backend-server 1 server-port 155
To reset the port to the default value of 443, enter:
(config-ssl-proxy-list[ssl_list1])# no backend-server 1 server-port
