2-3
Cisco TelePresence System 3000
OL-14521-01
Chapter 2 Building the Display Assembly
Parts List
Step 2 Attach the Codec Safety trays to the Front Foot stabilizers.
Note If you ordered a Presentation Codec, attach the larger tray that comes with the Presentation Codec
package, part no. 700-25301-xx, in the center display. For instructions to install the presentation codec,
refer to the “Options for the Cisco TelePresence System 3000” chapter of the Cisco TelePresence
Hardware Options and Upgrade Guide.
Figure 2-2 Codec Safety trays
201102
8
1112
