6-69

Hardware Installation Guide for Cisco 4000 Series Integrated Services Routers

OL-32185-02

Chapter 6 Install and Upgrade Internal Modules and FRUs

Install and Remove an SSD mSATA Storage Device

Install the SSD mSATA Storage Device

To install a SSD mSATA storage device:

Step 1 Read the “Safety Warnings” section on page 6-2 and disconnect the power supply before you replace any

module.

Step 2 Remove the chassis cover. For instructions on removing the chassis cover, see “Remove and Replace the

Chassis Cover” section on page 6-4.

Step 3 Place the SSD mSATA storage device on the SSD mSATA connector and align the device’s contact edge

with the corresponding socket in the connector.

Step 4 Press the device downward into the connector until it is level with the surface of the connector.

Step 5 While holding the device down, screw the device into place (see Figure 6-49).

Figure 6-49 Flash Memory Card and SSD mSATA Storage Device Locations

391828
