1-2
Cisco Wide Area Virtualization Engine 7541, 7571, and 8541 Hardware Installation Guide
Chapter 1 Introducing the Cisco Wide Area Virtualization Engine 7541, 7571, and 8541
Hardware Features
Front Panel Components and LEDs
Figure 1-1 shows the front panel components.
Figure 1-1 Front Panel
Figure 1-2 shows the front panel LEDs.
Figure 1-2 Front Panel LEDs
Table 1-1 describes the front panel LEDs and their functions.
1 Hard drive bays 0-7 (SAS device) 5 10/100/1000 GE 0/0 connector
2 Interface Module slot 6 10/100/1000 GE 0/1 connector
3 Console port (mini-USB) 7 External USB port
4 Console port (RJ-45) 8 Power On button
246573
1 2 4
3 7
5 6 8
246574
1 2 3 4
7
5
6
