Chapter 3 Installing the WAVE-7541, WAVE-7571, and WAVE-8541
Rack Mounting and Cabling the WAVE-7541, WAVE-7571, and WAVE-8541
Rack Mounting and Cabling the WAVE-7541, WAVE-7571,
and WAVE-8541
Note Rack-mounting the WAVE-7541, WAVE-7571, and WAVE-8541 appliance is supported in a 4-post rack
only.
Follow these steps to mount the WAVE appliance in a 4-post rack:
Step 1 Prepare for installation by reading Rack-Mounting Parts, Tools, and Considerations) and verify that you
have the correct tools and rack-mount hardware necessary for the installation.
Step 2 Attach the front rack mount brackets (item #1 in Table 3-1) using the six front bracket screws (item #4
in Table 3-1). (See Figure 3-1.)
Step 3 Attach the rear rack mount holder brackets (item #2 in Table 3-1) using the six rear bracket holder screws
(item #5 in Table 3-1).
Note The front arrow must point toward the front of the chassis.
Warning To prevent bodily injury when mounting or servicing this unit in a rack, you
must take special precautions to ensure that the system remains stable. The
following guidelines are provided to ensure your safety:
• This unit should be mounted at the bottom of the rack if it is the only unit in the
rack.
• When mounting this unit in a partially filled rack, load the rack from the bottom
to the top with the heaviest component at the bottom of the rack.
• If the rack is provided with stabilizing devices, install the stabilizers before
mounting or servicing the unit in the rack.
Statement 1006
