Cisco Wide Area Virtualization Engine 7541, 7571, and 8541 Hardware Installation Guide
Organization
This guide is organized as follows:
Conventions
Command descriptions use the following conventions:
Chapter Title Description
Chapter 1 Introducing the Cisco Wide Area
Virtualization Engine 7541,
7571, and 8541
Describes the physical properties and provides a
functional overview of the WAVE-7541,
WAVE-7571, and WAVE-8541.
Chapter 2 Preparing to Install the
WAVE-7541, WAVE-7571, and
WAVE-8541
Describes safety considerations and gives an
overview of the installation and procedures that you
should perform before the actual installation.
Chapter 3 Installing the WAVE-7541,
WAVE-7571, and WAVE-8541
Describes how to install the hardware and connect
the external network interface cables.
Chapter 4 Installing Hardware Options for
the WAVE-7541, WAVE-7571,
and WAVE-8541
Describes how to install Cisco Interface Modules,
hard disk drives, fans, and power supplies.
Chapter 5 WAVE Interface Modules Describes the features and cabling requirements of
the Cisco WAVE-7541, WAVE-7571, and
WAVE-8541 Interface Modules.
Chapter 6 Troubleshooting the System
Hardware
Describes troubleshooting procedures for the
hardware installation.
Appendix A WAVE-7541, WAVE-7571, and
WAVE-8541 Hardware
Specifications
Gives a summary of the hardware features and
specifications.
Appendix B Maintaining the WAVE-7541,
WAVE-7571, and WAVE-8541
Describes how to maintain the WAVE-7541,
WAVE-7571, and WAVE-8541.
Convention Description
boldface font Commands and keywords are in boldface.
italic font Variables for which you supply values are in italics.
[ ] Elements in square brackets are optional.
{x | y | z} Alternative keywords are grouped in braces and separated
by vertical bars.
[x | y | z] Optional alternative keywords are grouped in brackets and
separated by vertical bars.
string A nonquoted set of characters. Do not use quotation marks
around the string, or the string will include the
quotation marks.
