4-7
Cisco Unified IP Phone 7965G and 7945G Administration Guide for Cisco Unified Communications Manager 6.1(3)
OL-17755-01
Chapter 4 Configuring Settings on the Cisco Unified IP Phone
Network Configuration Menu
PC Port
Configuration
Speed and duplex of the access port (labeled 10/100/1000 PC).
Valid values:
• Auto Negotiate
• 10 Half—10-BaseT/half duplex
• 10 Full—10-BaseT/full duplex
• 100 Half—100-BaseT/half duplex
• 100 Full—100-BaseT/full duplex
• 1000 Full—1000-BaseT/full duplex
If the phone is connected to a switch, configure the port on the
switch to the same speed/duplex as the phone, or configure both to
auto-negotiate.
If you change the setting of this option, you should change the SW
Port Configuration option to the same setting. This ensures that the
PC receives the full benefits of the network operating speed.
1. Unlock network configuration
options.
2. Scroll to the PC Port
Configuration option and then
press the Edit softkey.
3. Scroll to the setting that you
want and then press the Select
softkey.
4. Press the Save softkey.
PC VLAN Allows the phone to interoperate with 3rd party switches that do
not support a voice VLAN. The Admin VLAN ID option must be
set before you can change this option.
1. Unlock network configuration
options.
2. Make sure the Admin VLAN
ID option is set.
3. Scroll to the PC VLAN
option, press the Edit softkey,
and then enter a new PC
VLAN setting.
4. Press the Validate softkey and
then press the Save softkey.
Table 4-2 Network Configuration Menu Options (continued)
Option Description To Change
