4-6
Cisco Unified IP Phone 7965G and 7945G Administration Guide for Cisco Unified Communications Manager 6.1(3)
OL-17755-01
Chapter 4 Configuring Settings on the Cisco Unified IP Phone
Network Configuration Menu
Domain Name Name of the Domain Name System (DNS) domain in which the
phone resides.
1. Unlock network configuration
options.
2. Set the DHCP option to No.
3. Scroll to the Domain Name
option, press the Edit softkey,
and then enter a new domain
name.
4. Press the Validate softkey and
then press the Save softkey.
Operational VLAN
ID
Auxiliary Virtual Local Area Network (VLAN) configured on a
Cisco Catalyst switch in which the phone is a member.
If the phone has not received an auxiliary VLAN, this option
indicates the Administrative VLAN.
If neither the auxiliary VLAN nor the Administrative VLAN are
configured, this option is blank.
The phone obtains its Operational
VLAN ID via Cisco Discovery
Protocol (CDP) from the switch to
which the phone is attached. To
assign a VLAN ID manually, use
the Admin VLAN ID option.
Admin. VLAN ID Auxiliary VLAN in which the phone is a member.
Used only if the phone does not receive an auxiliary VLAN from
the switch; otherwise it is ignored.
1. Unlock network configuration
options.
2. Scroll to the Admin. VLAN ID
option, press the Edit softkey,
and then enter a new Admin
VLAN setting.
3. Press the Validate softkey and
then press the Save softkey.
SW Port
Configuration
Speed and duplex of the network port (labeled 10/100/1000 SW).
Valid values:
• Auto Negotiate
• 10 Half—10-BaseT/half duplex
• 10 Full—10-BaseT/full duplex
• 100 Half—100-BaseT/half duplex
• 100 Full—100-BaseT/full duplex
• 1000 Full—1000-BaseT/full duplex
If the phone is connected to a switch, configure the port on the
switch to the same speed/duplex as the phone, or configure both to
auto-negotiate.
If you change the setting of this option, you should change the PC
Port Configuration option to the same setting. This ensures that the
PC receives the full benefits of the network operating speed.
1. Unlock network configuration
options.
2. Scroll to the SW Port
Configuration option and then
press the Edit softkey.
3. Scroll to the setting that you
want and then press the Select
softkey.
4. Press the Save softkey.
Table 4-2 Network Configuration Menu Options (continued)
Option Description To Change
