Cisco 7945G Administration Guide

4-20
Cisco Unified IP Phone 7965G and 7945G Administration Guide for Cisco Unified Communications Manager 6.1(3)
OL-17755-01
Chapter 4 Configuring Settings on the Cisco Unified IP Phone
Device Configuration Menu
Media Configuration Menu
The Media Configuration menu displays whether the headset, speakerphone, and video capability are
enabled on the phone. This menu also displays options for recording tones that the phone may play to
indicate that a call may be recorded.
Table 4-13 describes the options on this menu.
Ta b l e 4-13 Media Configuration Menu Options
Option Description To Change
Headset Enabled Indicates whether the Headset button is enabled on the
phone.
From Cisco Unified Communications
Manager Administration, choose
Device
> Phone > Phone
Configuration.
Headset
Hookswitch
Control Enabled
Indicates whether the wireless headset hookswitch feature
is enabled on the phone.
From Cisco Unified Communications
Manager Administration, choose
Device
> Phone >
Phone Configuration.
Speaker Enabled Indicates whether the speakerphone is enabled on the
phone.
From Cisco Unified Communications
Manager Administration, choose
Device
> Phone > Phone
Configuration.
Video Capability
Enabled
Indicates whether the phone can participate in video calls
when connected to an appropriately equipped computer.
From Cisco Unified Communications
Manager Administration, choose
Device
> Phone > Phone
Configuration.
Recording Tone Indicates whether a recording tone (often referred to as a
beep tone) is enabled or disabled for the phone. If the
recording tone option is enabled, the phone plays the beep
tone in both directions of every call, regardless of whether
the call actually gets recorded. The beep tone first sounds
when a call is answered.
You may want to notify your users if you enable this option.
Default: Disabled
Related Parameters:
• Recording Tone Local Volume
• Recording Tone Remote Volume
• Recording Tone Duration
Other related parameters—Beep tone frequency in hz, the
length of the beep tone (called duration), and how often the
beep tone plays (called interval)—are defined on a
per-Network Locale basis in the xml file that defines tones.
This xml file is usually named tones.xml or g3-tones.xml.
From Cisco Unified Communications
Manager Administration, choose
Device
> Phone > Phone
Configuration.

Cisco 7945G Specifications

General

Protocols	SCCP, SIP
Headset	Dedicated headset port
Speakerphone	Full-duplex speakerphone
Display	5-inch 320x240 pixel color display
Audio	Wideband audio support
Network	10/100 Ethernet switch
Power	IEEE 802.3af PoE
Lines	2 lines
Codecs	G.711, G.729a, G.722, iLBC
Weight	1 kg
