4-12
Cisco Unified IP Phone 7965G and 7945G Administration Guide for Cisco Unified Communications Manager 6.1(3)
OL-17755-01
Chapter 4 Configuring Settings on the Cisco Unified IP Phone
Device Configuration Menu
For an available Cisco Unified Communications Manager server, an option on the Unified CM
Configuration menu will show one of the Cisco
Unified Communications Manager server states shown
in
Table 4-4.
Note Select a server to see the host name and IP address.
An option may also display one of more of the designations or icons shown in Table 4-5.
Ta b l e 4-4 Cisco Unified Communications Manager Server States
State Description
Active Cisco Unified Communications Manager server from
which the phone is currently receiving call-processing
services.
Standby Cisco Unified Communications Manager server to
which the phone switches if the current server
becomes unavailable.
Blank No current connection to this Cisco Unified
Communications Manager server.
Ta b l e 4-5 Cisco Unified Communications Manager Server Designations
Designation Description
SRST Indicates a Survivable Remote Site Telephony router
capable of providing Cisco
Unified Communications
Manager functionality with a limited feature set. This
router assumes control of call processing if all other
Cisco
Unified Communications Manager servers
become unreachable. The SRST
Cisco
Unified Communications Manager always
displays last in the list of servers, even if it is active.
You configure an SRST router address in the Cisco
Unified Communications Manager SRST Reference
Configuration window (choose System > SRST). You
configure an SRST reference in the Device Pool
Configuration window (choose System > Device
Pool).
For more information, refer to Cisco Unified
Communications Manager Administration Guide.
TFTP Indicates that the phone was unable to register with a
Cisco Unified Communications Manager listed in its
configuration file, and it registered with the TFTP
server instead.
