Cisco 7945G Administration Guide

4-14
Cisco Unified IP Phone 7965G and 7945G Administration Guide for Cisco Unified Communications Manager 6.1(3)
OL-17755-01
Chapter 4 Configuring Settings on the Cisco Unified IP Phone
Device Configuration Menu
Related Topics
• Displaying a Configuration Menu, page 4-2
• Device Configuration Menu, page 4-11
Line Settings Menu (SIP Phones Only)
The Line Settings menu displays information that relates to the configurable parameters for each of the
lines on a SIP phone.
Table 4-7 describes the options in this menu.
Enable VAD This value is set to No by default. From Cisco Unified Communications
Manager Administration, choose
Device
>
Device Settings > SIP Profile.
Start Media Port Displays the start Real-Time Transport Protocol (RTP) range
for media.
From Cisco Unified Communications
Manager Administration, choose
Device
>
Device Settings > SIP Profile.
End Media Port Displays the end Real-Time Transport Protocol (RTP) range
for media.
From Cisco Unified Communications
Manager Administration, choose
Device
>
Device Settings > SIP Profile.
NAT Enabled Displays if Network Address Translation (NAT) is enabled.
This value will always be set to false.
Display only—cannot configure.
NAT Address Displays the WAN IP address of the NAT or firewall server.
This value will always be set to null.
Display only—cannot configure.
Call Statistics This value is set to No by default. From Cisco Unified Communications
Manager Administration, choose
Device
>
Device Settings > SIP Profile.
Table 4-6 SIP General Configuration Menu Options (continued)
Option Description To Change
Ta b l e 4-7 Line Settings Menu Options
Option Description To Change
Name Displays the lines and the number used to register each
line.
Use Cisco Unified Communications
Manager to modify.
Short Name Displays the short name configured for the line. Use Cisco Unified Communications
Manager Administration to modify.
Authentication Name Displays the name used by the phone for authentication if
a registration is challenged by the call control server
during initialization.
Use Cisco Unified Communications
Manager Administration to modify.
Display Name Displays the identification the phone uses for display for
caller identification purposes.
Use Cisco Unified Communications
Manager Administration to modify.

Cisco 7945G Specifications

General

Protocols	SCCP, SIP
Headset	Dedicated headset port
Speakerphone	Full-duplex speakerphone
Display	5-inch 320x240 pixel color display
Audio	Wideband audio support
Network	10/100 Ethernet switch
Power	IEEE 802.3af PoE
Lines	2 lines
Codecs	G.711, G.729a, G.722, iLBC
Weight	1 kg
