4-3
Cisco Video Surveillance 8620/8630 IP Camera Reference Guide
Chapter 4 Client Settings
Joystick settings
To enable joystick settings, follow these steps:
Step 1 Select a detected joystick, if there are multiple, from the Selected joystick menu. If your joystick is not
detected, if may be defective.
Step 2 Click Calibrate or Configure buttons to configure the joystick-related settings.
Note • If you want to assign Preset actions to your joystick, the preset locations should be configured in
advance in the Configuration > PTZ page.
• If your joystick is not working properly, it may need to be calibrated. Click the Calibrate button to
open the Game Controllers window located in Microsoft Windows control panel and follow the
instructions for trouble shooting.
• The joystick will appear in the Game Controllers list in the Windows Control panel. If you want to
check for your devices, choose Start > Control Panel > Game Controllers.
Buttons Configuration in Microsoft Windows
In the Button Configuration window, the left column shows the actions you can assign, and the right
column shows the functional buttons and assigned actions. The number of buttons may differ from
different joysticks.
To configure your joystick buttons, follow these steps:
Step 1 Choosing one of the actions and clicking Assign will pop up a dialog. Then you can assign this action
to a button by pressing the joystick button or selecting it from the drop-down list.
Step 2 Click OK to confirm the configuration.
Buttons Configuration on the Camera
Click the Configure Buttons button and the Joystick Settings window appears.
To configure your joystick buttons, follow these steps:
Step 1 Select a button number from the Button # pull-down menu.
Tip If you are not sure of the locations of each button, use the Properties window in the Game Controllers
utility.
Step 2 Select a corresponding action, such as Patrol or Preset#.
Step 3 Click the Assign button to assign an action to the button. You can delete an association by selecting a
button number, and then click the Delete button.
Repeat the process until you are done with the configuration of all preferred actions.
The buttons you define should appear on the button list accordingly.
