Cisco Video Surveillance 8620/8630 IP Camera Reference Guide
Chapter 1 Getting Started
LED Definitions
LED Definitions
Table 1-1 describes the LEDs on the Cisco Video Surveillance IP Camera.
Hardware Reset
The recessed button (see Figure 1-2 on page 1-3 for the 8620 or Figure 1-4 on page 1-4 for the 8630) is
used to reset the system or restore the factory default settings. Sometimes resetting the system can return
the camera to normal operation. If the system problems remain after reset, restore the factory settings
and install again.
• Reset—Press the recessed reset button. Wait for the camera to reboot.
• Restore—Press and hold the reset button until the status LED rapidly blinks. All settings will be
restored to factory default. Upon successful restore, the status LED will blink green and red during
normal operation.
MicroSD/SDHC/SDXC Card Capacity
The camera is compliant with SD/SDHC/SDXC 16GB / 8GB / 32GB / 64GB and other preceding
standard SD cards.
Network Deployment
The following sections provide information about deploying the camera on a network:
• General Connection (PoE), page 1-21
• Network Connection, page 1-22
Table 1-1 IP Camera LEDs
Item LED Status Description
1 Steady red Powered and system booting, or network
failed
Red LED off Power off
Green LED off Network disconnected
2 Steady Red and Green LED blinks every 1
sec.
Connected to network
3 Green LED blinks every 1 second and red
LED blinks consecutively every 0.15 second
Upgrading firmware
4 Green and red LEDs blink every 0.15 second,
green and red light on, then blink again
Restoring defaults
5 Red LED is on, green LED blinks, and red
LED is constantly on
Status after a reset (network connected)
Green and red LEDs are constantly on Status after a reset (network disconnected)
