Physical Description
• Mounting options—The cameras can be installed to a ceiling or wall.
Physical Description
The following figures illustrate the cameras:
• Figure 1-1 —Cisco Video Surveillance 8620 IP Camera outer view
• Figure 1-2—Cisco Video Surveillance 8620 IP Camera inner view
• Figure 1-3—Cisco Video Surveillance 8630 IP Camera outer view
• Figure 1-4—Cisco Video Surveillance 8630 IP Camera inner view
Figure 1-1 Cisco Video Surveillance 8620 IP Camera Outer View
1 PIR sensor
2 Microphone
3 Dome cover
