Figure 16: Adjust the Handset Rest
Procedure
Step 1 Remove the handset from the cradle and pull the plastic tab from the handset rest.
Step 2 Rotate the tab 180 degrees.
Step 3 Hold the tab between two fingers, with the corner notches facing you.
Step 4 Line up the tab with the slot in the cradle and press the tab evenly into the slot. An extension protrudes from
the top of the rotated tab.
Step 5 Return the handset to the handset rest.
Cisco IP Phone 8800 Series Multiplatform Phones Administration Guide
137
Hardware and Accessory Installation
Adjust the Handset Rest

Cisco 8800 Series Specifications

General

Protocols	SIP, SCCP
Audio	Wideband audio
Connectivity	Gigabit Ethernet
Power	Power over Ethernet (PoE)
Bluetooth	Yes
USB	Yes
Codec Support	G.711, G.722, G.729, iLBC
Dimensions	Varies by model
Weight	Varies by model
Wi-Fi	Yes (varies by model)
