Reset the Single LCD Screen Key Expansion Module
If you are having technical difficulties with your Cisco IP Phone 8800 Key Expansion Module, you can reset
the module to the factory default settings.
Procedure
Step 1 Restart the key expansion module by disconnecting the power source, waiting a few seconds, and then
reconnecting it.
Step 2 As the key expansion module powers up, press and hold Page 1. As the LCD screen turns white, continue
pressing Page 1 for at least one second.
Step 3 Release Page 1. The LEDs turn red.
Step 4 Immediately press Page 2 and continue pressing Page 2 for at least one second.
Step 5 Release Page 2. The LEDs turn amber.
Step 6 Press Lines 5, 14, 1, 18, 10, and 9 in sequence.
The LCD screen turns blue. A spinning icon is displayed in the center of the screen.
The key expansion module resets.
Configure a Speed Dial on a Key Expansion Module
You can configure speed dial on a key expansion module line. The user can then press the line key to call a
frequently dialed number.
You can also configure the parameters in the phone configuration file with XML(cfg.xml) code.
Before you begin
Access the Phone Web Interface.
Procedure
Step 1 Select Voice > Att Console.
Step 2 Select a key expansion module line key on which to enable the speed dial.
Step 3 Enter a string in this format:
fnc=sd;ext=9999@$PROXY;vid=n;nme=xxxx
where:
• fnc= sd means function=speed dial
• ext= 9999 is the phone that the line key calls. Replace 9999 with numbers.
• vid=n is the line index of the phone.
• nme= XXXX is the name displayed on the phone for the speed-dial line key. Replace XXXX with a
name.
