Cisco 8845 Administration Guide

Figure 16: Adjust the Handset Rest
Procedure
Step 1 Remove the handset from the cradle and pull the plastic tab from the handset rest.
Step 2 Rotate the tab 180 degrees.
Step 3 Hold the tab between two fingers, with the corner notches facing you.
Step 4 Line up the tab with the slot in the cradle and press the tab evenly into the slot. An extension protrudes from
the top of the rotated tab.
Step 5 Return the handset to the handset rest.
Cisco IP Phone 8800 Series Multiplatform Phones Administration Guide
137
Hardware and Accessory Installation
Adjust the Handset Rest

Cisco 8845 Specifications

General

Camera	No
Audio	Wideband audio
Speakerphone	Yes
Wi-Fi	No
Display	5-inch color display
Resolution	480 x 272 pixels
Ethernet	10/100/1000 Mbps
PoE	IEEE 802.3af/at
Protocols	SIP
Codecs	G.711, G.722, G.729a, iLBC
USB Ports	2 x USB 2.0
