Cisco 8845 Administration Guide

Multiple Paging Group Parameters
DescriptionFeature
Enter a string to configure group paging and priority paging (out of band paging) that
doesn’t require the phone registration.
Group Paging Script
LDAP
DescriptionParameter
Choose Yes to enable LDAP.
Default: No
LDAP Dir Enable
Enter a free-form text name, such as “Corporate Directory.”
Default: Blank
Corp Dir Name
Enter a fully qualified domain name or IP address of an LDAP
server in the following format:
nnn.nnn.nnn.nnn
Enter the host name of the LDAP server if the MD5 authentication
method is used.
Default: Blank
Server
Specify a starting point in the directory tree from which to search.
Separate domain components [dc] with a comma. For example:
dc=cv2bu,dc=com
Default: Blank
Search Base
Enter the distinguished name domain components [dc]; for
example:
dc=cv2bu,dc=com
If you are using the default Active Directory schema
(Name(cn)->Users->Domain), an example of the client DN
follows:
cn=”David Lee”,dc=users,dc=cv2bu,dc=com
cn=”David Lee”,dc=cv2bu,dc=com
username@domain is the client DN format for a Windows server
For example, DavidLee@cv2bu.com
Default: Blank
Client DN
Enter the username for a credentialed user on the LDAP server.
Default: Blank
User Name
Cisco IP Phone 8800 Series Multiplatform Phones Administration Guide
315
Cisco IP Phone Troubleshooting
Multiple Paging Group Parameters

Cisco 8845 Specifications

General

Camera	No
Audio	Wideband audio
Speakerphone	Yes
Wi-Fi	No
Display	5-inch color display
Resolution	480 x 272 pixels
Ethernet	10/100/1000 Mbps
PoE	IEEE 802.3af/at
Protocols	SIP
Codecs	G.711, G.722, G.729a, iLBC
USB Ports	2 x USB 2.0
