Cisco 8845 Administration Guide

DescriptionDefaultField Type
or Choices
Field
Enter a VLAN ID for the IP phone when you use a VLAN without
CDP (VLAN enabled and CDP disabled). Note that only voice
packets are tagged with the VLAN ID. Do not use the 1 value for
the VLAN ID. If VLAN ID is 1, you cannot tag voice packets
with the VLAN ID.
1VLAN ID
Enter a value of the VLAN ID that is used to tag communications
from the PC port on the phone.
The phone tags all the untagged frames coming from the PC (it
does not tag any frames with an existing tag).
Valid values: 0 through 4095
Default: 0
1PC port VLAN ID
Adds the ability to port mirror on the PC port. When enabled, you
can see the packets on the phone. Select On to enable PC port
mirroring and select Off to disable it.
OffOn
Off
PC port mirror
Enter a predefined DHCP VLAN option to learn the voice VLAN
ID.
When you use a VLAN ID with CDP, LLDP, or manually select
a VLAN ID, that VLAN ID takes precedent over the selected
DHCP VLAN option.
Valid values are:
• Null
• 128 to 149
• 151 to 158
• 161 to 254
Default value is null.
Cisco recommends that you use DHCP Option 132.
DHCP VLAN option
Cisco IP Phone 8800 Series Multiplatform Phones Administration Guide
43
Cisco IP Phone Installation
Network Configuration Fields

Cisco 8845 Specifications

General

Camera	No
Audio	Wideband audio
Speakerphone	Yes
Wi-Fi	No
Display	5-inch color display
Resolution	480 x 272 pixels
Ethernet	10/100/1000 Mbps
PoE	IEEE 802.3af/at
Protocols	SIP
Codecs	G.711, G.722, G.729a, iLBC
USB Ports	2 x USB 2.0
