Computer port (10/100 PC) connection5DC adapter port (DC48V)1
Handset connection6AC-to-DC power supply (optional)2
Analog headset connection (headset optional)7AC power wall plug (optional)3
Network port (10/100 SW) with IEEE 802.3af
and 802.3at power enabled
4
Cisco Unified IP Phone 8945
The Cisco Unified IP Phone 8945 provides these features:
•
Phone connections
Cisco Unified IP Phones 8941 and 8945 User Guide for Cisco Unified Communications Manager 9.0 (SCCP and
SIP)
2
Your Phone
Cisco Unified IP Phone 8945
