Cisco A9K-MOD400-TR User Manual

Change SummaryDate
Information added about the new 1-port 40GE Modular Port Adapter (MPA), the new 36-Port 10-Gigabit
Ethernet Line Card and the new 1-Port 100-Gigabit Ethernet Line Card, plus updates to the transceiver
module information.
September 2012
Information added about the new 160G modular line card, the new 2-port 10GE Modular Port Adapter
(MPA), the new 2-port 40GE Modular Port Adapter (MPA), and the CFP-40G, CFP-100G, and QSFP+
optical modules.
May 2012
Information added about the new 24-port 10GE fixed line card, the 2-port 100-GE fixed line card, and
the modular line card supporting the 20-port 1-GE Modular Port Adapter (MPA), the 4-port 10GE Modular
Port Adapter (MPA) and the 2-port 10GE Modular Port Adapter (MPA).
December 2011
Information added about the new 16x10GE SFP+ line card and SFP+ transceiver modules. Also added
information about additional versions of existing cards and new supported transceiver modules.
May 2010
Information added about the new 8x10GE 80 Gbps Line Rate Card and 2x10GE + 20x1GE Combination
Line Card.
December 2009
Initial release of this document.March 2009
Audience
This guide is written for hardware installers and system administrators of Cisco routers.
This publication assumes that the user has a substantial background in installing and configuring router and
switch-based hardware. The reader should also be familiar with electronic circuitry and wiring practices, and
have experience as an electronic or electromechanical technician.
Purpose
This installation guide contains procedures for installing line cards into the router, verifying the installation,
and creating a basic startup configuration file.
Organization
This guide includes the following sections:
DescriptionTitleSection
Provides instructions for installing the hardware and
connecting external network interface cables.
Overview, on page 11
Provides instructions for installing and removing line
cards and transceiver modules.
Installing and Removing Line Cards and Transceiver
Modules, on page 69
2
Cisco ASR 9000 Series Aggregation Services Router Ethernet Line Card Installation Guide
xi
Preface
Audience

Cisco A9K-MOD400-TR Specifications

General

Brand	Cisco
Model	A9K-MOD400-TR
Category	Network Router
Language	English
