The metal surfaces of CPF2-DCO modules may exhibit high temperature and can be unsafe for handling with
bare hands.
Caution
For more information about how to remove the CFP2-DCO module, see Safe Removal of CFP2-DCO Modules,
on page 87.
20-Port Gigabit Ethernet Modular Port Adapter with SFP
The 20-Port Gigabit Ethernet (GE) modular port adapter (MPA) provides 10 double-stacked SFP (20 total)
cages that support either fiber-optic or copper GE transceivers.
Each SFP cage on the 20-Port GE MPA has an adjacent A/L (Active/Link) LED visible on the front panel.
The A/L LED indicates the status of the associated SFP port, as described in table 20-Port Gigabit Ethernet
MPA LEDs . See Technical Specifications, on page 147 for a list of all SFP modules supported on the 20x1GE
modular port adapter.
Note: This MPA is not compatible with the consumption-model MOD400 line card.
Note
The following figure shows the 20-Port GE MPA and corresponding LEDs.
Cisco ASR 9000 Series Aggregation Services Router Ethernet Line Card Installation Guide
53
Overview
20-Port Gigabit Ethernet Modular Port Adapter with SFP
