Power Consumption ValuesDescription
520 W at 77°F (25°C)
560 W at 104°F (40°C)
600 W at 131°F (55°C)
2-Port 100G + 20-Port 10 GE Combination IPoDWDM Line Card with CFP2 and SFP+ (-TR)
Be sure that the chassis configuration complies with the required power budgets. Failure to properly verify
the configuration may result in an unpredictable state if one of the power units fails. Contact your local sales
representative for assistance.
Caution
Ethernet Line Card Physical Dimensions
For physical specifications, refer to the ASR 9000 Series line card data sheets:
https://www.cisco.com/c/en/us/products/routers/asr-9000-series-aggregation-services-routers/
datasheet-listing.html
Transceiver Module Specifications
For supported transceivers modules, refer to the Transceiver Module Group (TMG) Compatibility Matrix
Tool:
https://tmgmatrix.cisco.com/home
For transceiver module descriptions and specifications, refer to the data sheets:
Data Sheets
40-Gigabit QSFP and 100-Gigabit QSFP28 - 38-Pin Connector Specifications
SignalPinSignalPinSignalPinSignalPin
Reserved31RX2n21SCL11GND1
GND32RX2p22SDA12TX2n2
TX3p33GND23GND13TX2p3
TX3n34RX4n24RX3p14GND4
GND35RX4p25RX3n15TX4n5
TX1p36GND26GND16TX4p6
TX1n37ModPrsL27RX1p17GND7
GND38IntL28RX1n18ModSelL8
Cisco ASR 9000 Series Aggregation Services Router Ethernet Line Card Installation Guide
150
Technical Specifications
Ethernet Line Card Physical Dimensions
