Figure 79: Example Cable Routing through Cisco ASR 9006 Router Cable Management Brackets
Line Card Cable Management Bracket
This section describes the line card cable-management bracket. The following figure shows the line card
cable-management bracket attached to a 40-Port Gigabit Ethernet line card.
Cisco ASR 9000 Series Aggregation Services Router Ethernet Line Card Installation Guide
126
Installing and Removing Line Cards and Transceiver Modules
Line Card Cable Management Bracket
