Table 20: 8-Port 10-Gigabit Ethernet MPA LEDs
MeaningStateColorLED
Label
Port is not enabled.OffOffA/L
Port is enabled and the link is up.OnGreen
Port is enabled and the link is down.OnAmber
MPA power is off.
OffOffSTATUS
MPA is ready and operational.OnGreen
The MPA power is on and working is being configured.OnAmber
20-Port 10-Gigabit Ethernet Modular Port Adapter with SFP+
The 20-Port 10-Gigabit Ethernet (GE) modular port adapter (MPA) provides two 2x5 double-stacked cages
for SFP+ Ethernet optical interface modules.
Each SFP+ cage on the 20-Port 10GE MPA has an adjacent A/L (Active/Link) LED visible on the front panel
of the card as shown in the following figure. The A/L (Active/Link) LED indicates the status of the associated
SFP+ port, as described in Modular Port Adapter LEDs , on page 138.
Cisco ASR 9000 Series Aggregation Services Router Ethernet Line Card Installation Guide
59
Overview
20-Port 10-Gigabit Ethernet Modular Port Adapter with SFP+
