Figure 1: 2-Port 10-Gigabit + 20-Port GE Combination Line Card
1GE port 18 SFP cage6Ejector lever (one of two)1
Status LED710GE port 0 XFP cage2
1GE port 19 SFP cage8XFP port status LED (one
per XFP port)
3
1GE port 1 SFP cage91GE port 0 SFP cage4
Captive installation screw
(one of two)
10SFP port status LED (one
per SFP port)
5
Cisco ASR 9000 Series Aggregation Services Router Ethernet Line Card Installation Guide
16
Overview
2-Port 10-Gigabit + 20-Port Gigabit Ethernet Combination Line Card with XFP
