Figure 2: 8-Port 10-Gigabit Ethernet 2:1 Oversubscribed Line Card
Port 7 XFP cage4Ejector lever (one of two)1
Status LED5Port 0 XFP cage2
Captive installation screw
(one of two)
6Port status LED (one per
port)
3
Cisco ASR 9000 Series Aggregation Services Router Ethernet Line Card Installation Guide
18
Overview
8-Port 10-Gigabit Ethernet 2:1 Oversubscribed Line Card with XFP
