Figure 4: 8-Port 10-Gigabit Ethernet 80 Gbps Line Rate Card
Port 7 XFP cage4Ejector lever (one of two)1
Line card status LED5Port status LED (one per port)2
Captive installation screw (one of two)6Port 0 XFP cage3
Cisco ASR 9000 Series Aggregation Services Router Ethernet Line Card Installation Guide
22
Overview
8-Port 10-Gigabit Ethernet 80 Gbps Line Rate Card with XFP
