Figure 5: 4-Port 10-Gigabit + 16-Port GE Combination Line Card
Port status LED (one per
SFP+ port)
6Ejector lever (one of two)1
Line card status LED71GE port 0 SFP cage2
1GE port 15 SFP cage8Port status LED (one per
SFP port)
3
1GE port 1 SFP cage91GE port 14 SFP cage4
Cisco ASR 9000 Series Aggregation Services Router Ethernet Line Card Installation Guide
24
Overview
4-Port 10-Gigabit + 16-Port GE Combination Ethernet Line Card with SFP and SFP+
