Figure 6: 16-Port 10-Gigabit Ethernet Oversubscribed Line Card
Line card status LED5Ejector lever (one of two)1
Port 15 SFP+ cage6Port 0 SFP+ cage2
Port 7 SFP+ cage7Port status LED (one per
port)
3
Captive installation screw
(one of two)
8Port 8 SFP+ cage4
Cisco ASR 9000 Series Aggregation Services Router Ethernet Line Card Installation Guide
26
Overview
16-Port 10-Gigabit Ethernet Oversubscribed Line Card with SFP+
