Chapter 10 Scenario: Site-to-Site VPN Configuration
Implementing the Site-to-Site Scenario
10-2
ASA 5505 Getting Started Guide
78-18003-02
Figure 10-1 Network Layout for Site-to-Site VPN Configuration Scenario
Creating a VPN site-to-site deployment such as the one in Figure 10-1 requires
you to configure two adaptive security appliances, one on each side of the
connection.
Implementing the Site-to-Site Scenario
This section describes how to configure the adaptive security appliance in a
site-to-site VPN deployment, using example parameters from the remote-access
scenario shown in Figure 10-1.
This section includes the following topics:
• Information to Have Available, page 10-3
• Configuring the Site-to-Site VPN, page 10-3
