37
The following topics are covered in this section:
• Powering Off the Cisco ASR 1002-X Router Safely, page 37
• Replace the Cisco ASR1000-ESP5 or ASR1000-ESP10, page 37
• Replace the Shared Port Adapters, page 38
• Replace a Power Supply in the Cisco ASR 1002-X Router, page 39
Warning
Only trained and qualified personnel should be allowed to install, replace, or service this equipment.
Statement 1030
Powering Off the Cisco ASR 1002-X Router Safely
This section explains how to shut down the Cisco ASR 1002-X Router. It is recommended that before turning off all power to
the chassis, you issue the reload command. This insures that the operating system cleans up all the file systems. Once the reload
operation is complete, then the Cisco ASR 1002-X Router can be powered off safely.
To remove power from a Cisco ASR 1002-X Router safely, follow this procedure and see the examples:
Step 1 Slip on the ESD-preventive wrist strap that was included in the accessory kit.
Step 2 Enter the reload command.
Step 3 Confirm the reload command:
Router#reload
Proceed with reload? [confirm]
Aug 17 00:06:47.051 R0/0: %PMAN-5-EXITACTION: Process manager is exiting: prs exit with reload chassis
code
Step 4 After confirming the reload command, wait until the system bootstrap message displays before powering off the system.
System Bootstrap, Version 12.2(33r)XN2, RELEASE SOFTWARE (fc1)
Technical Support: tap://www.cisco.com/techsupport
Copyright (c) 2010 by cisco Systems, Inc.
Current image running: Boot ROM0
Last reset cause: LocalSoft
ASR1000-RP1 platform with 4194303 Kbytes of main memory
Router-rp0-rommon 1>
Step 5 Remove any power cables from the Cisco ASR 1002-X Router.
a. For power supplies with a circuit breaker switch, position the switch to the Off (O) position.
b. For power supplies with a Standby switch, place the Standby switch in the Standby position.
Note After powering off the router, wait a minimum of 30 seconds before powering it on again.
Replace the Cisco ASR1000-ESP5 or ASR1000-ESP10
This section provides instructions for removing the Cisco ASR1000-ESP5 or ASR1000-ESP10 from the Cisco ASR 1002-X
Router. The Cisco ESP5 and ESP10 are Cisco Quantum Flow Processors (QFP) for the Cisco ASR 1002-X Router. The Cisco
ESP5 and ESP10 are individual FRUs and support online insertion and removal operation. Before you begin, make certain the
chassis is grounded.
