To remove the Cisco ESP5 or ESP10 from the Cisco ASR 1002-X Router, follow this procedure:
Step 1 Slip on the ESD-preventive wrist strap that was included in the accessory kit. Loosen the captive screws on the Cisco
ESP5 or ESP10.
Step 2 Using the handles on both sides of the module, with two hands, gently slide the Cisco ESP5 or ESP10 out of the chassis
slot.
Note Handle the Cisco ESP5 and ESP10 by the carrier edges only; never touch the printed circuit board components or
connector pins.
Step 3 Place the Cisco ESP5 or the ESP10 on an antistatic surface with its printed circuit board components facing upward or
in a static shielding bag.
You have completed the procedure for removing the Cisco ESP5 or ESP10.
To install the Cisco ESP5 or ESP10 in the Cisco ASR 1002-X Router, follow this procedure:
Step 1 Slip on the ESD-preventive wrist strap that was included in the accessory kit.
Step 2 Using the handles on both sides of the module, with two hands, gently insert the Cisco ESP5 or -ESP10 into the top
chassis slot.
Note Handle the Cisco ESP5 and ESP10 by the carrier edges only; never touch the printed circuit board components or
connector pins.
Step 3 Once the board is seated, tighten the captive screws.
Step 4 Place the Cisco ESP5 or Cisco ESP10 on an antistatic surface with its printed circuit board components facing upward
or in a static shielding bag.
You have completed the procedure for replacing the Cisco ESP5 or ESP10.
Replace the Shared Port Adapters
The shared port adapters (SPAs) on the embedded Cisco ASR1000-SIP10 in the Cisco ASR 1002-X Router support online
insertion and removal (OIR); but the embedded Cisco ASR1000-SIP10 does not support OIR and is not field-upgradeable.
Note Cabling information is included with the specific shared port adapter documentation.
Before removing any shared port adapter, shut down the interface so that there is no traffic running through the shared port
adapter when it is removed. Removing a shared port adapter while traffic is flowing through the ports can cause system
disruption.
Step 1 Attach an ESD wrist strap between you and an unpainted chassis surface.
Step 2 Disconnect all cables from the shared port adapter.
Step 3 Remove the shared port adapter from the chassis subslot. Grasp the handle and pull the shared port adapter or blank
panel from the router.
Step 4 Locate the shared port adapter slot guides inside the Cisco ASR 1002-X Router.
