Cisco ASR 1002 Quick Start Guide

7
Tip To allow space to attach the cable-management brackets to the chassis in the rack easily, make certain that you use the
rack-mount bracket ear holes specified in Step 9.
Step 8 Hold the chassis in position against the mounting rails and follow these steps:
a. Insert the bottom screw into the second ear hole from the bottom of the rack-mount ear and use a hand-held screwdriver
to tighten the screw to the rack rail.
b. Insert the top screw into the second bracket hole from the top of the rack-mount bracket ear hole diagonally from the
bottom screw and tighten the screw to the rack rail. See Figure 3.
c. Repeat these steps for the other side of the chassis.
Note As a result of using the specified rack-mount bracket ear holes, the cable-management bracket can be easily
attached to the rack-mount bracket after the chassis is in the rack.
This completes the procedure for installing the chassis in a four-post rack. Proceed to the “Attach the Cable-Management
Bracket” section on page 8 to continue the installation.
Two-Post Rack Installation
Note Make certain that you attach the cable-management bracket to the chassis after you install the chassis in an equipment
rack.
Note Inner clearance (the width between the inner sides of the two posts or rails) must be at least 19 inches (48.26 cm).
Airflow through the chassis is from front to back.
Figure 4 Installing a Cisco ASR 1002 Router in a Two-Post Rack
1
Rack equipment rail
2
Rack-mount bracket ear and holes
280282
ASR
10
02
s
t
a
t
pwr
m
i
n
m
a
j
c
r
i
t
S
P
A-
4
XOC
3
-
P
O
S
ST
A
T
U
S
0
1
2
3
C
/
A
A
/
L
C
/
A
A
/
L
C
/
A
A
/
L
C
/
A
A
/
L
S
P
A-
4
XOC
3
-
P
O
S
S
T
A
T
U
S
0
1
2
3
C
/
A
A
/
L
C
/
A
A
/
L
C
/
A
A
/
L
C
/
A
A
/
L
S
P
A
-
4
X
O
C
3
-
P
O
S
S
T
A
T
U
S
0
1
2
3
C
/
A
A
/
L
C
/
A
A
/
L
C
/
A
A
/
L
C
/
A
A
/
L
1
2

Cisco ASR 1002 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.3
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
DHCP client	-
Supported network protocols	BGP, GRE, OSPF, DVMRP, EIGRP, IS-IS, IGMPv3, PIM-SM, PIM-SSM
Ethernet LAN (RJ-45) ports	4
Security algorithms	SSH
VPN tunnels quantity	8000
Safety	UL60950-1 CSA, C22.2 No. 60950-1-03, EN 60950-1, IEC 60950-1, AS/NZS 60950.1
Certification	FCC 47CFR15 Class A AS/NZS CISPR 22 CISPR 22 Class A EN55022 Class A ICES-003 Class A VCCI Class A CNS-13438 Class A EN61000-3-2 EN61000-3-3
Internal memory	4096 MB
AC input voltage	85 - 264 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (typical)	560 W
Operating altitude	0 - 3048 m
Storage temperature (T-T)	0 - 50 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	5 - 90 %
Product color	Gray
Rack capacity	2U

Weight and Dimensions

Depth	461 mm
Width	437.4 mm
Height	89 mm
Weight	- g
