The followng image shows the ASR1006-PWR-DC power supply for the Cisco ASR 1006 Router.
Figure 20: Cisco ASR 1006 Router DC Power Supply (ASR1006-PWR-DC) Terminal Block Plastic Cover
Plastic cover slotted area3Negative lead1
Terminal block plastic cover4Positive lead2
Cisco ASR 1000 Series Router Hardware Installation Guide
37
Cisco ASR 1006 Router Overview and Installation
Connecting DC Input Power to Cisco ASR 1006 Router
