ASR 1000 Series SIP slot
0
5Slot RP0 with ASR 1000
Series RP1
1
ASR 1000 Series SIP slot
1
6Slot RP1 with ASR 1000
Series RP1
2
ASR 1000 Series SIP slot
2
7Slot FP0 with ASR 1000
Series ESP
3
——
Slot FP1 with ASR 1000
Series ESP
4
The Cisco ASR 1006 Router contains three Cisco ASR 1000 Series SPA Interfaces (SIPs) that support four
subslots for the installation of SPAs.
Figure 4: Cisco ASR 1006 Router — SIP Subslots, on page 5 shows the Cisco ASR 1006 Router SPA
subslot location.
Figure 4: Cisco ASR 1006 Router
—
SIP Subslots
Installation Methods
Although rack-mounting is the preferred method of installation for the Cisco ASR 1006 Router, you can
mount the chassis:
•
On an equipment shelf or tabletop
•
In a19-inch wide (standard), 4-post equipment rack or two-post, using the rack-mount brackets in the
accessory kit
The Cisco ASR 1006 Router usually ships fully loaded. However, you can remove components from the
chassis to make the chassis lighter for your rack installation.
Note
General Rack Installation Guidelines
When planning your rack installation, consider the following guidelines:
•
The Cisco ASR 1006 Router requires a minimum of 6 rack units (10.45 inches or 26.6 cm) of vertical
rack space. Measure the proposed rack location before mounting the chassis in the rack.
•
Before using a particular rack, check for obstructions (such as a power strip) that could impair rack-mount
installation. If a power strip does impair a rack-mount installation, remove the power strip before installing
the chassis, and then replace it after the chassis is installed.
Cisco ASR 1000 Series Router Hardware Installation Guide
5
Cisco ASR 1006 Router Overview and Installation
Installation Methods
