Cable-management bracket2
Step 6
Screw the cable-management bracket to each side of the rack-mount brackets already attached to the chassis. For each
cable-management bracket, use two screws from the package of four screws.
Step 7
Ensure that all the screws are securely tightened.
Step 8
Go to the Attaching a Chassis Ground Connection, on page 23 for instructions about completing the installation.
Rack-Mounting the Cisco ASR 1006 Router
The Cisco ASR 1006 Router can be installed with both front or rear rack-mount brackets. The chassis
rack-mounting flanges are secured directly to the chassis before you lift it into the rack. For installing Cisco
ASR 1006 Router rack-mount brackets, go to:
Verifying Rack Dimensions
Before you install the chassis, measure the space between the vertical mounting flanges (rails) on your
equipment rack to verify that the rack conforms to the measurements shown in the following image.
SUMMARY STEPS
1.
Mark and measure the distance between two holes on the left and right mounting rails.
2.
Measure the space between the inner edges of the left front and right front mounting flanges on the
equipment rack.
DETAILED STEPS
Step 1
Mark and measure the distance between two holes on the left and right mounting rails.
The distance should measure 18.31 inches ± 0.06 inches (46.5 cm ± 0.15 cm).
Measure for pairs of holes near the bottom, middle and top of the equipment rack to ensure that the rack posts
are parallel.
Note
Step 2
Measure the space between the inner edges of the left front and right front mounting flanges on the equipment rack.
Cisco ASR 1000 Series Router Hardware Installation Guide
10
Cisco ASR 1006 Router Overview and Installation
Rack-Mounting the Cisco ASR 1006 Router
