DETAILED STEPS
Step 1
Remove the two M3X5mm screws and discard.
Step 2
Install AC cord retainer by inserting tabs into lance features on panel.
Step 3
Secure AC cord retainer with two M3X8mm screws included in kit.
Step 4
Connect AC power cord.
Step 5
Secure AC cord by tightening retainer screw.
What to Do Next
Cisco ASR 1000 Series Router Hardware Installation Guide
42
Cisco ASR 1006 Router Overview and Installation
Attaching Cable Retention Bracket on AC Power Supply
