Cisco ASR 9000 Series Installation Guide

Table 14: Alphanumeric Displays and LEDs at System Startup
Display Contents/LED Status and MeaningType of IndicatorComponent
INIT—Card is inserted and microcontroller is initialized
BOOT—Board is powered on and CPU is booting
IMEM—Start initializing memory
IGEN—Start initializing the board
ICBC—Start initializing communication with the microcontroller
PDxy—Loading programmable devices (x = FPGA, y = ROMMON)
PSTx—Power on self test x
RMN—All tests are finished and ROMMON is ready for commands
LOAD—Downloading Minimum Boot Image (MBI) image to CPU
MBI—Starting execution of MBI
IOXR—Cisco IOS XR software is starting execution
ACTV—RSP role is determined to be active RSP
STBY—RSP role is determined to be standby RSP
PREP—Preparing disk boot
Alphanumeric displayRSP card
Cisco ASR 9000 Series Aggregation Services Router Hardware Installation Guide
200
Troubleshooting the Installation
Identifying Startup Issues

Cisco ASR 9000 Series Specifications

General

Series	ASR 9000
Category	Network Router
Modular Design	Yes
Redundancy	Yes (Hardware and Software)
Operating System	Cisco IOS XR
Interfaces/Ports	10G, 40G, 100G, 400G Ethernet
Expansion Slots	Varies by model
Routing Protocol	BGP, OSPF, IS-IS, EIGRP
Management	CLI, SNMP, NETCONF
Power Supply	Redundant
Port Density	Varies by model
Power Supply Options	AC, DC
Memory	Varies by model
Storage	Varies by model
Dimensions	Varies by model
Weight	Varies by model
