Cisco ASR 9001 Overview And Reference Guide

2-59
Cisco ASR 9000 Series Aggregation Services Router Overview and Reference Guide
OL-17501-09
Chapter 2 Functional Description
Power System Functional Description
Figure 2-49 Cisco ASR 9904 Router AC Power System Block Diagram—Version 2 Power System
AC Power Shelf with
AC/DC Power Supply Modules
Power Distribution
Backplane
AC/DC
Pwr Sply
Module-
A0
3KW
EMI
Filter
–54V
–54V
–54V
–54V RTN
–54V
–54V
AC1-1
220V
20A 1O
390182
AC/DC
Pwr Sply
Module-
A1
3KW
EMI
Filter
AC1-2
220V
20A 1O
AC/DC
Pwr Sply
Module-
A2
3KW
EMI
Filter
AC1-3
220V
20A 1O
AC/DC
Pwr Sply
Module-
A3
3KW
EMI
Filter
AC1-4
220V
20A 1O
Line Card (x1)
Soft-Start
Circuit,
EMI Filter
Narrow
Range,
Fixed
Ratio
(5:1)
10.8V
Converter
Point of
Load
(POL)
Converters
RSP Card (x2)
Soft-Start
Circuit,
EMI Filter
Narrow
Range,
Fixed
Ratio
(5:1)
10.8V
Converter
Point of
Load
(POL)
Converters
Fan Tray
Soft-Start
Circuit,
EMI Filter
Fan
Controller
and
Cooling
Fans
–54V
–54V
–54V
–10.8V
–10.8V
Line Card (x1)
Soft-Start
Circuit,
EMI Filter
Narrow
Range,
Fixed
Ratio
(5:1)
10.8V
Converter
Point of
Load
(POL)
Converters
–54V
–10.8V

Cisco ASR 9001 Specifications

General

Router Series	ASR 9000 Series
Rack Units	2 RU
Operating System	Cisco IOS XR
Form Factor	Rack-mountable
Power Supply	AC or DC
Memory	8 GB
Forwarding Capacity	Up to 80 Gbps
Switching Capacity	160 Gbps
Operating Temperature	0 to 40°C
Weight	24 lb
Redundancy	Power supply
