Chapter 3 High Availability and Redundant Operation
Power Supply Redundancy
Figure 3-9 DC System Power Redundancy for the Cisco ASR 9006 Router Version—2
Figure 3-10 DC System Power Redundancy for the Cisco ASR 9904 Router—Version 2
Figure 3-11 DC System Power Redundancy for the Cisco ASR 9922 Router—Version 2
344092
2100W DC
2100W DC
2100W DC 2100W DC 2100W DC 2100W DC
2100W DC 2100W DC 2100W DC 2100W DC
14,700W DC system
7+1 max power redundancy
2,100W DC system 1+1 min
power redundancy
2100W DC
2,100W DC system 1+1 min power
redundancy
6,300W DC system
3+1 max power redundancy
2100W DC 2100W DC 2100W DC 2100W DC 2100W DC
390185
344096
2100W DC 2100W DC 2100W DC 2100W DC 2100W DC 2100W DC 2100W DC 2100W DC
2100W DC 2100W DC 2100W DC 2100W DC
2100W DC 2100W DC 2100W DC 2100W DC
2100W DC 2100W DC 2100W DC 2100W DC
6,300W DC system
3+1 min power redundancy
31,500W DC system
15+1 max power redundancy

Cisco ASR 9001 Specifications

General

Router Series	ASR 9000 Series
Rack Units	2 RU
Operating System	Cisco IOS XR
Form Factor	Rack-mountable
Power Supply	AC or DC
Memory	8 GB
Forwarding Capacity	Up to 80 Gbps
Switching Capacity	160 Gbps
Operating Temperature	0 to 40°C
Weight	24 lb
Redundancy	Power supply
