Cisco ASR 903 Hardware Installation Guide

Interface Module LEDs
The table below summarizes the LEDs for the interface modules.
The Status LED is Amber for the 10 Gigabit Ethernet ports when operating in WAN mode for the following:
•
8x1 Gigabit Ethernet SFP + 1x10 Gigabit Ethernet SFP+ Interface Module
•
8x1 Gigabit Ethernet RJ45 + 1x10 Gigabit Ethernet SFP+ Interface Module
•
2x10 Gigabit Ethernet SFP+ Interface Module
Table 35: Interface Module LEDs
DescriptionColor/StateLED
Disabled/no power to IMOffPower (PWR)
Enabled and power rails on IM in
range
Green
Disabled/power-downOffStatus (STAT)
Failure (on at reset)Red
Booting (if local CPU)Flashing Red
OperationalGreen
Inactive or no connectionOffLink status (L)
Fault/loop conditionAmber
Ok with activity or no activityGreen
Inactive port statusOffSpeed (S)
Activity or no activityGreen
OC-3 and OC-192 Interface Module LEDs
The table below summarizes the LEDs for the OC-3 and OC-192 interface module.
Cisco ASR 903 Aggregation Services Router Hardware Installation Guide
163
Troubleshooting
Interface Module LEDs

Cisco ASR 903 Specifications

General

Form Factor	Modular
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Humidity	5% to 95% non-condensing
Redundancy	Yes, redundant power supplies and route processors
Operating System	Cisco IOS XE
Power Supply	AC or DC
Switching Capacity	240 Gbps
Operating Temperature	-40°C to 65°C (-40°F to 149°F)
MTBF	200, 000 hours
Supported Protocols	IPv4, IPv6, MPLS, L2VPN, L3VPN
Interfaces	Gigabit Ethernet, 10 Gigabit Ethernet, T1/E1
